MRCOOL 17,000 BTU 17.3 SEER2 Heat Pump Condenser - DIYS-18-HP-C-230A11-O
The MRCOOL® DIY® Select 18K BTU 230V Ductless Heat Pump Single Zone Mini-Split Condenser is designed to make HVAC installation simple and accessible for homeowners. Built for true do-it-yourself installation, it requires no specialized tools, certifications, or prior HVAC experience. Ideal for garages, home offices, studios, and similar spaces, it delivers reliable heating and cooling for areas up to 800 square feet. Despite its DIY®-friendly design, the system delivers strong performance with a 17.3 SEER2 cooling rating and 8.5 HSPF2-4 heating efficiency, providing consistent, energy-efficient comfort year-round while helping control utility costs. Installation is further simplified with an 11.5-foot Quick Connect® line set that arrives factory pre-charged with environmentally friendly R-454B refrigerant, eliminating the need for vacuum pumps or refrigerant handling. Most components are included, making setup faster and more approachable for first-time installers. Comfort control is easy using the included wireless remote or the MRCOOL® Comfort app, which allows remote temperature control, scheduling, and energy monitoring. Compatibility with Amazon Alexa and Google Assistant adds hands-free convenience. Features like Sleep Mode, Dry Mode, Auto, and a Gold Fin® condenser coating enhance comfort and durability, even in humid or coastal environments. For added peace of mind, the MRCOOL® DIY® Select system is backed by a 2-year compressor warranty and a 1-year parts warranty.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | MRCOOL |
| Model Number | DIYS-18-HP-C-230A11-O |
| Product Type | Heat Pump Condenser |
| Series | DIY Select |
| Tonnage | 1.5 |
| Cooling Capacity | 17,000 BTU |
| Heating Capacity | 18,000 BTU |
| SEER2 | 17.3 |
| EER2 | 9 |
| Refrigerant | R-454B |
| Voltage | 208/230 V |
| Phase | 1 |
| Color | White |
| Unit Dimensions | 21.85"H x 30.12"W x 11.93"D |
| Shipping Weight | 82.23 lb |
| Parts Warranty | 1 Year Parts |
| Compressor Warranty | 2 Years Compressor |
| Warranty | 1 Year Parts, 2 Years Compressor |
Compliance & Shipping Notices
- WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Warranty Coverage
1 Year Parts, 2 Years Compressor
Professional Installation Required
Certified HVAC technician installation ensures optimal performance, safety compliance, and full warranty protection.
DOE Compliant Nationwide
This equipment meets Department of Energy efficiency requirements for residential HVAC installations across all U.S. climate zones.
Important: Check state and local codes and ordinances before purchasing. Product availability and compliance requirements may vary by region.
