Goodman GR9S921004CN Up to 92% AFUE Gas Furnace
The Goodman GR9S921004CN is a Up to 92% AFUE single-stage gas furnace delivering 92,100 BTU/h of reliable heating output from a 100,000 BTU/h input. Featuring a multi-speed ECM blower motor and durable aluminized steel heat exchanger, this furnace provides efficient and dependable home heating performance.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Goodman |
| Model Number | GR9S921004CN |
| Product Type | Gas Furnace |
| BTU Input | 100,000 BTU/h |
| BTU Output | 92,100 BTU/h |
| AFUE | Up to 92% |
| Stages | Single-Stage |
| Blower Motor | Multi-Speed ECM |
| Blower HP | 3/4 HP @ 1075 RPM |
| Blower Size | 10" x 10" |
| Min Circuit Ampacity | 13.7 A |
| Max Overcurrent Protection | 20 A |
| Temperature Rise | 35-65°F |
| Vent Diameter | 2" - 3" |
| Cabinet Width | 21" |
| Dimensions (W×D×H) | 21" × 19½" × 34½" |
| Weight | 141 lbs |
Comprehensive Warranty Protection
10
Year Parts Warranty
∞
Lifetime Heat Exchanger Warranty
Professional Installation Required
Certified HVAC technician installation ensures optimal performance, safety compliance, and full warranty protection.
DOE Compliant
This gas furnace meets Department of Energy efficiency requirements for residential heating applications
Goodman's standard 10 year parts warranty when registered online through the manufacturer.
