Daikin MXM 18K BTU 2-Zone Heat Pump R-32

Description

• Energy Star Certified: Yes
• Refrigerant Type: R-32
• Unit Height: 29-1/2 in
• Unit Width: 34-1/4 in
• Regional Compliance:
  • North
  • Southeast
  • Southwest
• Max Overcurrent Protection: 20 A
• Power Phase: 1 Ph
• Power Voltage: 208-230 V
• Compressor Stages: Inverter
• Compressor Type: Swing
• Unit Weight: 127 lb
• Tonnage: 1.5
• Unit Depth: 12-5/8 in
• Heat Exchanger Type: Air Cooled

Where the 2MXM18AVJU9 fits

This is the 2-zone MXM outdoor unit by itself: 18,000 BTU of total capacity to be divided across up to 2 indoor heads, which are bought separately. It is how you condition 2 rooms that each want their own thermostat from a single outdoor unit and a single set of penetrations.

The compressor is inverter-driven and the refrigerant is R-32. It runs on 208-230 V, so it needs a dedicated 240-volt circuit. The part that needs planning is the head selection: the indoor units you choose have to stay within the total capacity and the port count, and Daikin publishes combination tables for exactly that. Tell us which rooms you are covering and we will work the combination out with you before anything ships.

See the rest of the line in Daikin MXM multi-zone equipment, or start from the room instead with our HVAC sizing tool. For help matching an indoor unit to an outdoor unit, call (877) 843-4822 and we will check the model numbers against Daikin’s tables before you buy.
