MRCOOL 3 Ton 16.1 SEER2 Heat Pump Condenser – MVP-36-HP-C-230A00-O
$2,106.83
-
Product Details
- Model Number
- MVP-36-HP-C-230A00-O
- Brand
- MRCOOL
- Condition
- New
Description
The MVP-36-HP-C-230A00-O — MRCOOL 3 Ton 16.1 SEER2 Heat Pump Condenser – MVP-36-HP-C-230A00-O — is stocked and shipped by Buy Comfort Direct from Winder, Georgia. Specifications, fitment notes and ordering details are below; call (877) 843-4822 if you need it matched to your equipment first.
About the MVP-36-HP-C-230A00-O
MRCOOL 3 Ton 16.1 SEER2 Heat Pump Condenser – MVP-36-HP-C-230A00-O
The 3 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser offers a reliable and cost-effective solution for heating and cooling your home throughout the year. This unit is built for durability and efficiency, providing dependable comfort in any season.
With a variable-speed 36k capacity, the VersaPro® delivers solid performance with a SEER2 rating of 16.1 and an HSPF4 rating of 8.7. These efficiency levels ensure effective heating and cooling while keeping energy costs manageable. When paired with the MRCOOL® VersaPro® Central Ducted Air Handler, it forms a well-rounded system suited to your home’s needs. DC inverter technology ensures smooth operation and energy savings, making it a great choice for replacing older, less efficient systems. Included with the system is the MRCOOL® Smart thermostat,allowing for effortless temperature adjustments.
The VersaPro® condenser uses R-454B refrigerant, an eco-friendly option that helps reduce its environmental impact. Its durable painted galvanized steel construction is designed to last, while the compact side-discharge design simplifies installation in tighter spaces. The self-diagnostic system makes maintenance easier, helping to reduce the need for service calls.
For added peace of mind, the 3 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser comes with a 10-year warranty that covers the compressor and parts. This warranty ensures long-term reliability and protection for your investment.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | MRCOOL |
| Model Number | MVP-36-HP-C-230A00-O |
| Product Type | Heat Pump Condenser |
| Series | VersaPro® Central Ducted Condenser |
| Tonnage | 3 |
| Cooling Capacity | 36,000 BTU |
| Heating Capacity | 36,000 BTU |
| SEER2 | 16.1 |
| EER2 | 10 |
| Refrigerant | R-454B |
| Voltage | 208/230 V |
| Phase | 1 |
| Color | Gray |
| Unit Dimensions | 31.89″H x 37.24″W x 16.14″D |
| Shipping Weight | 163.58 lb |
| Parts Warranty | 10 Years |
| Compressor Warranty | 10 Years |
Warranty Coverage
10 Years
Professional Installation Required
Certified HVAC technician installation ensures optimal performance, safety compliance, and full warranty protection.
DOE Compliant Nationwide
This equipment meets Department of Energy efficiency requirements for residential HVAC installations across all U.S. climate zones.
Important: Check state and local codes and ordinances before purchasing. Product availability and compliance requirements may vary by region.
MVP-36-HP-C-230A00-O: fitment and resources
Equipment ratings are only valid as an AHRI-matched pairing; confirm the match before ordering. Our free HVAC system sizing tool gives a starting point for tonnage, and Background reading: the U.S. Department of Energy heat pump guide. Browse the rest of our Condensers or the MRCOOL catalog, and see what customers say on our reviews page.
Ordering and delivery
In-stock items ship from our Winder, Georgia warehouse; orders over $99 ship free. Large equipment travels by freight carrier and parts by ground, with tracking by email. Financing is available at checkout through Affirm, and contractors can set up a contractor account for trade pricing. Questions before you pay? Use the contact page or call (877) 843-4822.
MVP-36-HP-C-230A00-O FAQ
Does the MVP-36-HP-C-230A00-O ship free?
Yes on orders over $99 — most orders that include it qualify.
How do I know it fits my system?
Send us your equipment model number through the contact page or call (877) 843-4822 and we will confirm the match before it ships.
Additional information
| Weight | 163.58 lbs |
|---|---|
| Dimensions | 0.00 × 0.00 × 0.00 in |
| System Type | Mini Split |
| Brand | MRCOOL |
| Tonnage | 3 Ton |
| SEER2 | 16.1 |
| Refrigerant | R-454B |
| Voltage | 208/230V |
