Haier 3 Ton 18.0 SEER2 R-454B Heat Pump - 1U36T3PC1HE
brand: Haier
- SKU:
- 1U36T3PC1HE
- Condition:
- New
- Shipping:
- Free Shipping
Haier 3 Ton 18.0 SEER2 R-454B Heat Pump - 1U36T3PC1HE
The 1U36T3PC1HE outdoor condenser unit delivers efficient cooling performance for your home with a 3-ton capacity and 17.5 SEER2 rating. Designed as part of a single condenser system, this unit operates with R-454B refrigerant to provide reliable climate control. As a dedicated outdoor component, it works to remove heat from your indoor space and maintain consistent comfort throughout the cooling season.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Haier |
| Model Number | 1U36T3PC1HE |
| Product Type | Heat Pump Outdoor Unit (Inverter Split) |
| Tonnage | 3 Ton |
| Cooling Capacity (BTU/h) | 36000 BTU/h |
| Heating Capacity (BTU/h) | 36000 BTU/h |
| SEER2 Rating | 18.0 |
| Defrost Type | Demand |
| Refrigerant Type | R-454B |
| Compressor Type | Inverter |
| Voltage/Phase/Frequency | 208-230V/1-Ph/60Hz |
| Min Circuit Ampacity | 24 A |
| Max Overcurrent Protection | 35 A |
| Factory Charge (oz) | 94 oz |
| Liquid Line Size | 3/8" |
| Suction Line Size | 7/8" |
| Sound Level (dBA) | 75 dBA |
| Dimensions (H×W×D) | 33.062" x 43.125" x 19.875" |
| Shipping Weight | 213.8 lbs |
Features
- 3.0 ton cooling capacity outdoor condensing unit
- 17.5 SEER2 energy efficiency rating
- R-454B refrigerant for reduced environmental impact
- Single condenser design for streamlined installation
Warranty Coverage
Professional Installation Required
Certified HVAC technician installation ensures optimal performance, safety compliance, and full warranty protection.
DOE Compliant Nationwide
This equipment meets Department of Energy efficiency requirements for residential HVAC installations across all U.S. climate zones.
Important: Check state and local codes and ordinances before purchasing. Product availability and compliance requirements may vary by region.
